Sontek QC4
.webp)
The future of waterway management utilizing machine learning to automate water monitoring in flood prone sites.
.jpg)
Product
Vision Without Limits
Eliminating the need for manual water level measurements, the QC2 continuously monitors flow rates in water ways, providing accurate information on water usage, flood risk and rainfall flows, even where gauging was previously unsafe or impossible.
.webp)
.webp)
Partnership
A Confluence Of Engineering
Integrating dual stereo cameras, optical flow tracking, and cloud-based machine learning into a compact, rugged system, our team worked hand-in-hand with Xylem to realize their vision for a non-contact system that operates reliably and efficiently without routine servicing in the harshest of climates.
.webp)
Working with the Ingenuity team was a terrific experience. Their integrated approach to electronic, software, and mechanical design brought our product vision to life with precision and innovation.
Impact
Setting A New Standard
Through protecting communities with enhanced flood forecasting, reducing site-visit related carbon emissions & increasing worker safety, the Sontek-QC4 inspires broader adoption of ethical, low-impact practices across environmental industries. It embodies a scalable, future-ready solution that supports global efforts toward a safer, more resilient, and more sustainable world. Here are a few features which make it such a breakthrough:
Key Features
Feature set
Software
Machine Vision Using Jeston Orin NX Processor
Intelligent Power Management Logic
Secure Remote Configuration and Acces
Realtime Video Acquisition
Automated Wake & Sleep Schedules
Custom Board Support Package
Hardware
Jetson Orin Nx System-on-Module with Custom Carrier Board Implementation
STM32 Microcontroller for Watchdog and Power Sequencing
High-Speed USB3, PCIe & Gigabit Ethernet Interfaces
Internal PCIe Solid State Storage
Cellular, Wi-Fi & LPWAN Connectivity
GNSS/GPS Receiver with External LNA
USB3 & MIPI-CSI-2 Interfaces to an Integrated Adapter Card for 2 GMSL Stereo-Vision Cameras
Internal Battery with Buck-Boost Charge Controller and Coulomb Counter
On-board Temperature, Pressure and Humidity Sensors.
3-Axis Accelerometer
Mechanical
IP67 Rated Enclosure
Active Cooling with Heat Dissipating Casing
Dual Axis Modular Mounting System
Integrated EMC Shielding
Adaptive Enclosure Design For Future Iteration
Tamper Proof Fastening System
